Description
MRCOOL DIY MULTI ZONE 5-ZONE 48K BTU CONDENSER, 4TH GEN SERIES
Introducing the latest in home comfort solutions with the new 4th Generation MRCOOL DIY 48K BTU Ductless Heat Pump Condenser (DIY-MULTI5-48HP230C) that can support up to 5 zones. When paired with select MRCOOL air handlers, it has the ability to achieve a SEER efficiency rating of up to 20.5. This condenser also has the capability to continue to deliver heating performance when temperatures reach 5°F. It has also been constructed to hold up against the weather and resist corrosion with its durable Gold Fin Condenser coating. MRCOOL also offers this condenser with a limited lifetime compressor warranty for additional peace of mind.
Even with all of these features and performance, this Do-It-Yourself condenser still has the ability to be installed by a homeowner without needing a certified technician. It is designed to be installed using MRCOOL’s patented Pre-Charged Quick Connect Line Sets. These line sets come pre-charged with R-410A refrigerant and can be connected by using simple hand tools. So, no vacuuming of the system is required once installed. Let the MRCOOL 4th Generation DIY 48K BTU 5 Zone Ductless Heat Pump Condenser be the answer to your multi-zone heating and cooling home comfort.
Features
- Up to 21 SEER
- Gold Fin® condenser: corrosion resistant - live on the coast? Don't worry, our condenser is built to resist long term corrosion
- Energy Efficient DC Inverter
- R-410A environmentally friendly refrigerant
- Standard 7-year compressor/5-year parts warranty; register for limited lifetime compressor warranty
Specifications
| Product Dimensions | 37.48"W x 16.34"D x 52.48"H |
| Product Weight | 222.89 lbs |
| SEER | 20.5 |
| EER | 11 |
| HSPF | hspf4/hspf5 : 11/8.5 |
| CFM | 4500 |
| Cooling Capacity | 48000 BTU |
| Heating Capacity | 48000 BTU |
| Voltage |
Requires a minimum of 208V-230V/60HZ/40-60A (please check your home meets this electrical requirement prior to purchase) |
| Phase | 1 |
| Cycle | 60 Hz |
| Max Fuse Breaker |
60 A |
| Min Circuit Ampacity | 40 A |
| Color | White |
| Zone Capacity | Up to 5 |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 162 oz |
| Decibel Rating | 61.5 dBA |
| Inverter | Yes |
| Min Ambient Cool | 5F ~ 122F |
| Min Ambient Heat | 5F ~ 75.2F |
| Max Lineset Length | 221.5 ft TOTAL |
| Liquid Line Size | 1/4in |
| Suction Line Size | 3/8in +1/2in |
| Compressor Motor Type | Rotary |
| Condenser Fan Motor RPM | 900/850/800/750 |
| Wifi Compatibility | Yes |
| App Compatibility | Yes |
| Compatible with | IOS Android |
| Warranty | 5-year Parts/7-year Compressor Registered Warranty: Limited Lifetime Compressor |
Users Manual
